Description
Vibrating knife acoustic board cutting machine, the cutting thickness is about 1-10CM (depending on the material), using the blade to cut, no need to manufacture a large number of molds, the cutting process will not produce bevel problems, cutting without debris, for Hole-shaped products with smaller apertures can be punched and cut with punching knives. The entire cutting process is environmentally friendly and pollution-free.
Product Parameter
| Model | YC-1625L（customizable） |
| Working area | 2500mm*1600mm |
| Max Cutting speed | 1200mm/s |
| Cutting tolerance | ±0.1mm |
| Cutting thickness | 0.1-10mm |
| Multifunctional head | Vibrating knife,pneumatic knife ,milling tool |
| Applicable materials | graphite, rubber, asbestos-free sheets, PTFE, silicone, and fiber composites |
| Operation properties | Online / offline operation; continuous cutting with high efficiency, 7*24 with zero downtime |
| Safety device | Emergency button, anti-collision device, infrared sensor |
| Transmission interface | Ethernet |
| Drive system | Motor: Panasonic servo motor Guide rail and rack |
| Fixed mode | Vacuum absorb |
| Supply voltage | 220V 380V±10%,50HZ 60HZ |
| Rated power | 11KW |
