Description
The Epson FA45002 printhead delivers exceptional productivity and image quality with its advanced MACH technology and high-density 300 npi/2-row configuration. Compatible with both UV and eco-solvent inks, this printhead is engineered for reliable performance across demanding production environments.
Cross-Reference Compatibility:
- Roland VS Series: 6701409010
- Mutoh VJ Series: DG-43988
Important: Always replace head cables when installing a new printhead to ensure optimal performance and longevity.
Product Specifications:
- Ink type: UV / Eco Solvent
- Type: MACH (Multi Layer Actuator Head)
- Width x Depth x Height: 60.4 x 46.9 x 71.1 mm
- Weight: 97g
- Number of nozzle: 1440
- Nozzle pitch/ nozzle row: 1/180 inch
- Nozzle rows: 8 rows
- Nozzle Resolution: 180 npi/ row, 360 npi/ 2 rows
- Max. number of colours ink: 8 colours
- Effective print width: 25.4mm (1 inch)
- Droplet ejection performance:
- Binary: 10 pl at 40kHz
- 4 levels grey scale: 4.5, 10, 19pl at 20kHz
- Viscosity range: 6-8mPa·s
- Country of origin : Japan
The following items are expressly excluded from warranty coverage:
- defects related, in any way, to the use of non-original inks
- clogged, missing or deviated nozzles
- defects related to misuse, abuse, accident, neglect, lack of use, or improper storage when not in use for extended periods
- defects related to failure to perform periodic maintenance as specified in the user documentation; operation for unintended purposes
- defects related to improper loading of media
- all other defects, failures or damage not considered manufacturing defects
- defects related to third-party applications, software, parts, components, or peripheral devices, including any bulk ink system.
- defects that are merely cosmetic in nature.
